Hoggi BINGO Evolution - Headrest with Occiput Upholstery; Thorax Pads

32
•Aftertighteningthescrews,thebackupholsteryispushedunderneath
thetrunkpads.
•Theangleofthetrunkpadisxedbytighteningtheclampingscrew
underneaththetrunkpadcover.
Wheneveryouchangeanysettings,makesure
thatyourmlytightenanyscrewsthathavebeen
loosened.
6.8Trunksupports
Thetrunkpadsaremountedtothebackwithbackupholsteryremoved.
Thetrunkpadgetspositionedasshownintheillustrationandthescrew
getspluggedthroughthelongholeinthebackrestplate.Thetriangular
padguidinggetspluggedfromthebackside.
Thestampinginthepadguidingmustbepositionedintothelonghole.
Atleastawashergetpluggedandthewingnutgetsrmlytightened.
Afterlooseningthewingnutitispossibletoadjustthetrunkpad
steplesslyconcerningtheheight.Bytwistingfromthehorizontaltothe
uprightpositionitispossibletoadjustthewidthofthepadstoeachother.
6.7 Headrest with occiput upholstery
(inconnectionwithuniversaljoint)
Afterlooseningthecounternutontheuniversaljointitispossibleto
adjusttheheadrestthreedimensional.
Afterlooseningtheupperwingnutitispossibletoadjusttheheadrestby
thelongholeinthedepth.
Afterlooseningofbothwingnutsitispossibletoadjusttheheadrestby
usingthelockwasher.Theblanksheetinsidetheupholsterycanbe
adjustedtotheheadshape.Thecovercanberemovedforcleaning.
Theillustrationshowstheheadrestwithocciputupholstery.
