Hoggi BINGO Evolution - Chest-Shoulder Harness

39
•Readjustthebucklesifnecessary.
Closingthexationjacket:
•Placeyourchildintotheseat.
•Closethezipper.
•Tacktogetherthefastenersontheshoulders.
Toputthechest-shoulderharnesson:
•Beforeseatingthechildinthepushchair,releasethefourcam-lock
bucklesonthebackplate.
•Pullthechestandshoulderpadslightlytothefront,openthehinged
camsatthelowerendofthepadandpullthestrapsout.
•Placethestrapsonthesidesoftheseat.
•Placeyourchildintotheseat.
•Pullthechestandshoulderpadovertheheadontothechest.
•Next,threadthestrapsintothelowercam-lockbucklesofthepadall
thewaytothestoprivetsandclosethebuckles.
•Thentightenthelowerstrapsfrombehind.
6.16 Chest-shoulder harness
Toattachthechest-shoulderharness,rivet(frominsidetooutside)the
fourcam-lockbucklestotheoutsideofthebackplate.Guidethe
shoulderstrapsforthechest-shoulderharnessbackwardsthroughthe
designatedslots.Threadthelowerstrapsthroughtheslotsinthelower
partofthebackbase(seealso6.9Lapbelt)totherear.Threadall
strapsthroughtheopencam-lockbucklesandclampinpositionby
closingthehingedcam.
Caution!
Excessstrapendsonaccessoriesmaybetrappedin
thetiltmechanismandcanavoidtheengagementof
thelockingpins.Insuchacasetheseatcouldfalloff
themobilitybase.Shortenexcessstrapendson
accessoriessothattheycannotbetrapped.
