6.26Drumbrakes
BINGOEvolutioncanbettedwithdrumbrakestoo.
Thedrumbrakesareactivatedfromthepush-bar.
Attheexitofeachbrakehousingacrankedsetscrewleadsthe
brakecableawayfromthetyreoftherearwheel.Afterlooseningthe
counternutthepretensionoftheindividual(leftorright)brakecan
beadjusted.
Tightenthecounternutrmlyagainandensurethatthecrankofthe
setscrewshowstowardstherearframe,awayfromthetire.
Adjustments:
Theattendantbrakesetispreadjusted.
Nevertheless,ifadjustmentsbecomenecessaryjustafterinstallationor
afteraperiodofusetherearefollowingoptions:
Afterlooseningthecounternuttheinitialtensioncanbeadjustedby
screwingtheguideofthebowdencable.
Wheneveryouchangeanysettings,makesure
thatyourmlytightenanyscrewsthathavebeen
loosened.
Eachdrumbrakeisoperatedbyabrakelever.Toapplythedrumbrake
squeezethebrakelever.
Withthengertipspresstherockingcatch,untilitlockswithaclickand
releasethebrakehandle.
Whenthebrakeleverissqueezedagain,therockingcatchisunlocked
andthedrumbrakecanbereleased.
