Attachments C250 ... C370
Translation of Original Operating Manual 156319-04 169
1 Pictogram
2 Shutoff valve for rear lift and tipping system or
lateral adjustment
3 Button for rear lift and tipping system or lateral
adjustment
4 Preselect switch for floating position
5 Preselect switch for double/single-acting
Position A Front lift side adjustment
Position B Rear lift, tipping system
Changing over to lateral adjustment
1. Switch hydraulic valve (2) to position (A).
Lateral adjustment is activated.
2. You can move the front lift to the left or the
right by pushing button (3).
3. The front lift will remain in the selected posi-
tion after button 3 is released.
4. Select additional functions with buttons (4,
5). See "Passive inclination adjustment", page
167
ADVICE
The rear lift or the tipping system can-
not be used if lateral adjustment is ac-
tivated.
Changing over to rear lift and tipping system
1. Switch hydraulic valve (2) to position (B).
Lateral adjustment is deactivated.
2. You can operate the rear lift or the tipping
system by appropriately pressing button (3).
See "Tipping system, rear lift", page 180.
