HOLEMAKER PRO 40 - Technical Data

TECHNICAL DATA
6
Supply voltage: ………………………………… 220-240V/ 50-60 Hz.
Motor power ……………………………………………………. 1020 W
Total power …………………………………………………….. 1100 W
Machine speeds (under load): ………………....................... 440rpm
Insulation class ………………………………………………….. First
Tool holder …………………………………. (
3
/
4
" Weldon) 19.05 mm
Capacities: max. holemaker cutter diameter …………............. 40mm
max. drilling depth with standard arbor ………...... 52mm
Magnet Dead Lift (on 25 mm plate) ………......................... 10650 N
Dimensions:
electromagnetic base …...................................... 84x168x41.5 mm
Length of the power cord ……………………............................. 3 m
Total weight ………………………………...…...................... 12.5 kg
Noise level ……………………………………………...……....... 85 dB
84mm
168mm
298mm
278mm
385 - 509 mm
180mm
255mm
49
mm
49
mm
107mm
