HOLMS 300
10 © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 141204.
Product data
2.2 2.5 3.0
Working width (m) 2.2 2.5 3.0
Max width (m) 2.4 2.7 3.2
Max height without hook (m) 1.3 1.3 1.3
Water tank volume (litres) 400 400 400
Effective refuse volume (approx. litres) 360 660 700
Weight, empty (kg)
a
a. Weights and centres of gravity excluding attachment.
470 570 650
Additional weight with side brush (per brush) (kg) 70 70 70
Weight, full water tank and full container (kg)
b
b. Applies to material with a density of 1.4-1.5.
1395 1935 2055
Centre of gravity, dimension A (empty) (mm) 140 140 130
Centre of gravity, dimension B (empty) (mm) 320 340 340
Max oil flow (litres/min) 2000/4000 motors 130/210 130/210 130/210
