Replacement of the Swish brush
NOTE: THIS BRUSH CORE DOES NOT NEED TO BE
DISMANTLED PRIOR TO BRUSH REPLACEMENT.
Swish is equipped with a cassette brush, see figure 23.
Brush replacement
1. Loosen the catch, see figure 24.
2. Turn the outer stop to the open position, see figure 25.
3. Pull out the spent cassettes, see figure 26.
4. Rotate the roller so that all cassettes can be extracted.
5. Slide in the new brush cassettes.
6. Rotate the roller so that all cassettes can be inserted.
7. Lock the catch, see figure 24.
8. Turn the outer stop to its locked position, see figure
27.
Tip
Lubricating the tracks with soap or the like will simplify
brush replacement.
23.Cassette brush
24.Catch
25.Open
position
26.Replacing the
brush
27.Locked position
