HOLMS 300
14 © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 141204.
Emptying the refuse container
Lift up the machine and tilt it backwards so that the refuse
can be emptied.
Carefully rotate the roller a few turns to free it from
rubbish.
Disconnection from carrier
Disconnect the sweeper from the carrier as follows:
1. Lower and secure the supports in the parking position.
2. Release the hydraulic quick-couplings and electric
cable.
3. Release the machine attachment lock pins and tilt the
attachment forward as far as possible. The machine
can then be put on the ground. See figure 3 on page
12.
Connection of side brush (extra equipment)
Connection of the side brush is done by taking the control
unit to the driver's seat and attaching it using magnets.
The attendant plugs are placed in a 12/24 volt socket.
Sprinkler
The pump must not be run when dry, i.e. once the water
has been used up the pump must be switched off.
The machine is equipped with two water filters to prevent
dirt getting into the system. One filter sits in the tank
filling hole, while the other is located on the suction side
of the pump. Both filters can be flushed clean and reused.
The filters must be in position when the tank is filled, as
otherwise there is a danger that the pump and water
system will be damaged.
When there is a risk of freezing: empty the water in the
water tank, water pump, filter and attendant hoses. The
Be careful to ensure that the machine's bar tube
does not become jammed against the loader arms
when the machine is lifted.
The brush becomes deformed if the sweeper is not
parked on the supports.
This is important as, otherwise, the sweeper may
be damaged by the loader arms.
