Holo audio Spring 2 User Manual

4 | P a g e
Specifications
COAXIAL1, COAXIAL2,
OPTICAL, AES
PCM 44.1-192K (24bit)
DSD 64X （DOP）
USB
PCM 44.1K-1.536M (32bit)
DSD 64-512X （DOP）
DSD 64-1024X （Native）
I2S
PCM 44.1K-1.536M (32bit)
DSD 64-1024X
PCM 48K NOS
THD+N 0.0006% @1K
SNR -124dB
Voltage Output 1.9Vrms(RCA), 3.8Vrms(XLR)
DSD 128X
THD+N 0.0008% @1K
SNR -118dB
Voltage Output 0.95Vrms(RCA), 1.9Vrms(XLR)
Size
430x300x55mm / 16.93x11.81x2.17inch (WxLxH Dimensions do not
include protruding parts）
Weight
8.5kg/18.74lbs
Power input (configurable,
depending on the bottom
label of the machine）
220-230V 50/60Hz 2A
110-115V 50/60Hz 4A
Power consumption
40W
Accessories
Power Cable x1 (North America only)
USB Cable x1
Remote Control x1 (Not Included in Level 1 models)
