4.2 Cabinet mounting
 Separating the parts of the CUBE
The part made of wood can be used as a
drilling template for the cabinet door (or
you may have already processed this with
the CNC program).
 Now screw the two halves of the CUBE to
the cabinet door and connect them to
each other using the integrated plug
connector.
 Install the housing with the connections
facing down.
Note
The CUBE can be integrated into the edge
rack, for example.
Drawings for the installation of the CUBE
can be downloaded free of charge. For
information on how to do this, see the
enclosed installation instructions.
Note
The part made of wood is superfluous.
