OPERATION
1 Litre + 20 ml =
2 Litres + 40 ml =
3 Litres + 60 ml = 50:1 (2%)
4 Litres + 80 ml =
5 Litres + 100 ml =
OPERATING THE TRIMMER (Fig. 5)
Hold the trimmer with the right hand on the rear handle
and the left hand on the left handle. Keep a firm grip
with both hands while in operation. Trimmer should be
held at a comfortable position with the rear handle about
hip height.
Always operate trimmer at full throttle. Cut tall grass from
the top down. This will prevent grass from wrapping
around the shaft housing and bump head which may
cause damage from overheating. If grass becomes
wrapped around the bump head, stop the engine,
disconnect the spark plug wire, and remove the grass.
Prolonged cutting at partial throttle will result in oil
dripping from the silencer.
ADVANCING THE LINE
ADVANCING LINE USING THE EZ LINE™ TAP
ADVANCE SYSTEM
Line advance is controlled by tapping the bump head on
grass while running engine at full throttle.
■ Run engine at full throttle.
■ Tap bump head on the ground to advance line.
Line advances each time the head is tapped.
■ Several taps may be required until line strikes the
cut off blade.
■ Resume trimming.
Note: If the line is worn too short you may not be
able to advance the line by tapping it on the ground.
If so, STOP THE ENGINE, and manually advance
the line.
ADVANCING THE LINE MANUALLY
Push the bump head down while pulling on line(s) to
manually advance the line.
CUTTING TIPS (Fig. 6)
■ Keep the trimmer tilted toward the area being cut;
this is the best cutting area (24).
■ Do not cut in dangerous cutting area (23).
■ Use the tip of the line to do the cutting; do not force
bump head into uncut grass.
■ Wire and picket fences cause extra line wear, even
breakage. Stone and brick walls, curbs, and wood
may wear line rapidly.
■ Avoid trees and shrubs. Tree bark, wood moldings,
siding, and fence posts can easily be damaged by
the line.
SAFETY GUARD LINE TRIMMING CUT-OFF
BLADE (Fig. 7)
This trimmer is equipped with a line trimming cut-off
blade on the safety guard. For best cutting, advance line
until it is trimmed to length by the cut-off blade. Advance
line whenever you hear the engine running faster than
normal. This will maintain best performance and keep
line long enough to advance properly.
STARTING AND STOPPING (Fig. 8 & 9)
WARNING
Never start or run the engine inside a closed or
poorly ventilated area; breathing exhaust fumes
can kill.
TO START A COLD ENGINE:
■ Lay trimmer on a flat, bare surface. Move ignition
switch (8) to “I” (RUN) position.
Note: Unit is equipped with a positive on-off switch,
make sure switch is in the “I” (RUN) position before
starting the unit.
■ Push primer bulb (27) 4 times.
■ Set choke lever (11) to choke position (31).
■ Depress throttle interlock (26), squeeze throttle trigger
(4) and pull starter grip (1) until engine tries to run.
(No more than 6 pulls.)
■ Set choke lever to half choke position (30).
■ Hold trigger and pull starter rope until engine runs.
■ Run engine 15 to 30 seconds at full throttle (with
trigger depressed fully) on half choke position (30) to
warm up. Move choke lever to run position (29).
TO START A WARM ENGINE:
■ Lay trimmer on a flat, bare surface. Move ignition
switch to “I” (RUN) position.
■ Move choke lever to run position (29).
■ Mold trigger and pull starter grip (1) until engine runs.
TO STOP THE ENGINE:
To stop the engine, depress the switch (8) to the “O”
position.
