−See pages for important safety
information and warnings about how to
properly position the seats and seat-
backs.
13 14
On EX, EX-L, and EX-SE models
Moving the long horizontal switch
adjusts the seat bottom in several
directions. The seat bottom adjusts
in the direction you move the switch.
The short vertical switch adjusts the
seat-back angle.
The controls for the adjustable
driver’s power seat are on the
outside edge of the seat bottom. You
can adjust the power seat with the
ignition switch in any position. Make
all seat adjustments before you start
driving.
Adjusts the seat-back
angle forward or
backward.
Moves the seat
forward and backward.
Moves the front of the
seat up or down and
the rear of the seat up
or down.
Raises or lowers the
seat.
Seats
Power Seat Adjustments
Instruments and Controls
87
