Honda BF2.3D - Lubrication Points

46
SERVICING YOUR OUTBOARD MOTOR
Apply Honda Marine Corrosion Inhibitor (or equivalent) to all areas under the engine cover and any exposed metal
surfaces.
Lubrication Points
Apply Honda Marine waterproof grease to the parts
shown below:
Lubrication interval:
10 operating hours or one month after the date of
p
urchase or initial use, then every 50 operating hours or 6
months.
To prevent corrosion, apply anticorrosion oil to pivot
s
urfaces where grease cannot penetrate.
●THROTTLE ARM
●TILT LEVER
●CLAMP SCREW
●THROTTLE ARM
●CHOKE ARM
●STEERING HANDLE
●SWIVEL CASE
●STEERING FRICTION BOLT
●TRANSOM ANGLE
ADJUSTING BOLT
●THRUST RECEIVER
