Engine Oil u Changing Clutch Oil Filter
74
Changing Clutch Oil Filter
Use a new Honda Genuine clutch oil filter or
equivalent specified for your model.
1.
Follow the steps 1-6 of Changing Engine
Oil & Filter. 2 P. 72
2.
Remove the right under cowl. 2 P. 67
3.
Remove the clutch oil filter cover, clutch
oil filter and spring by removing the
clutch oil filter cover bolts.
u Discard the oil and clutch oil filter at
an approved recycling centre.
Using the wrong clutch oil filter can result in serious
damage to the transmission.
Clutch oil
filter cover
O-ring
Spring
Clutch
oil filter
OUT-SIDE
mark
Rubber seal
Bolts
14 CTX700-32MJF8000.book 74 ページ ２０１３年５月９日 木曜日 午後９時５９分
