13-3
HRX217HYA • HRX217HZA TRANSMISSION
12.Slide the transmission toward the long axle shaft until the
short axle shaft is free of the mower deck, and remove the
transmission. The clutch cable can be left connected to
the transmission.
13.Remove the two 22 mm circlips and plain washers from
the axle shafts.
TRANSMISSION
CLUTCH
CABLE
CIRCLIP,
22 mm (2)
PLAIN WASHER,
22 mm (2)
