MAINTENANCE HRX217HYA • HRX217HZA
8. GRASS BAG
CLEANING
Wash a dirty grass bag with a garden hose, and allow it to dry
completely before use. A wet bag will clog quickly
.
REPLACEMENT
Replace a worn or damaged bag with a Honda Genuine
replacement bag or its equivalent.
1. Unclip the plastic edges of the bag from the frame.
2. Remove the bag from the frame.
3. Insert the frame into the replacement bag, as shown.
4. Clip the plastic edges of the bag onto the frame, as shown.
Assemble the grass bag frame by pulling the support legs
outward and sliding them into the eyelets as shown.
.
BAG FRAME HANDLE
EYELETS
FABRIC GRASS BAG
SUPPORT LEGS
