1-3

HRX217HYA • HRX217HZA SPECIFICATIONS

2. DIMENSIONAL DRAWINGS

678 mm (26.7 in)

588 mm (23.1 in)

530 mm (20.9 in)

1,122 mm (44.1 in)

1,665 mm (65.5 in)

HZA type shown:
