uuFusesuFuse Locations
Handling the Unexpected
■
Circuit protected and fuse rating
Circuit Protected Amps
1
MAIN FUSE 150 A
IG MAIN 1 30 A
SUB FAN MTR 30 A
IG MAIN 2 30 A
OP FUSE MAIN 30 A
ESB 40 A
ENG EWP 30 A
2
WIPER MOTOR 30 A
R/M 2 30 A
P-ACT 30 A
R/M 1 30 A
COOLING FAN 30 A
EPS 70 A
3
BLOWER MOTOR 40 A
ABS/VSA MOTOR 40 A
FUSE BOX OPTION
*
(40 A)
ABS/VSA FSR 40 A
PREMIUM AUDIO
*
(30 A)
REAR DEFROSTER 40 A
4
−30 A
−30 A
FUSE BOX 2 40 A
FUSE BOX 1 60 A
5 IGPS 7.5 A
6VBU 10 A
7 IG HOLD1 10 A
8 PCU EWP 10 A
9 IGP 15 A
10 BACK UP 10 A
11 IGPS (LAF) 7.5 A
12 EVTC 20 A
13 HAZARD 10 A
14 IG COIL 15 A
15 DBW 15 A
16 STOP LIGHTS 10 A
17 − −
18 − −
19 AUDIO 15 A
20 FR FOG LIGHT
*
(15 A)
Circuit Protected Amps
21 AS P/SEAT RECLINING
*
(20 A)
22 AS P/SEAT SLIDE
*
(20 A)
23 HORN 10 A
24 WASHER 15 A
25 SHIFTER 10 A
26 SMART 10 A
27 − −
28 P-ACT UNIT 10 A
29 IGB 10 A
30 − −
Circuit Protected Amps
* Not available on all models
