Honda Miimo HRM1500 Miimo HRM1500 Live User Manual

Specifications
116
10
TECHNICAL INFORMATION
Specications
Model HRM1000 HRM1500 HRM1500Live
Description code MCJF MCKF MCLF
Type E B S E B S EC BC SC
Length 655 mm
Width 535 mm
Height 270 mm
Weight 11.3 kg 11.3 kg 11.5 kg
Electrical system
Battery
Li-ion
21.6 V / 1900 mAh
AC adapter
Input
AC 230 V AC 240 V AC 230 V AC 230 V AC 240 V AC 230 V AC 230 V AC 240 V AC 230 V
Output 1.5 A / 40 V
Extension cord ICC 2X1.5 mm
2
, conform with H07RN-F
Mowing
Blade motor speed 2500
0
-100
min
-1
(Normal mode) / 2200
0
-100
min
-1
(Quiet mode)
Cutting height 20-60 mm
Cutting width 22 cm
Boundary wire
Maximum possible length
(Option parts)
400 m
Frequency band(s) 2.5 kHz - 5 kHz
Maximum radio-
frequency power
< 82 dBµA/m @10m
Communication
Bluetooth
®
class 2 (10 mW)
Bluetooth
®
version 4.0
Frequency band(s) 2402MHz - 2480MHz
Maximum radio-
frequency power
< 20 mW
Noise
Sound pressure level at
operator’s ears
EN50636-2-107:2015
Measured level 48 dB(A)
Measuring uncertainty +2.5 dB(A)
(Not exceeding 70 dB(A))
Sound power level
EN50636-2-107:2015
Measured level 55.9 dB(A)
Measuring uncertainty +2.5 dB(A)
Garden size
Maximum area 1000m² 1500m² 1500m²
Recommended area 800m² 1000m² 1000m²

Honda Miimo HRM1500 Miimo HRM1500 Live Specifications

General

Maximum Area	1500 m²
Battery Type	Lithium-ion
Battery Voltage	22.2 V
Type	Robotic Lawn Mower
Cutting Height Adjustment	Manual
Noise Level	62 dB(A)
Cutting Width	220 mm
Charging Time	60 min
Operating Time	30 min
