69
4 MENU SETTINGS
Checking the system
Test start points
You can check whether the lawnmower can correctly return to the docking
station, and whether it can reach each start points according to settings.
Test start points
Home screen J [3.Diagnostics] J [2.Test start points] J
[1.Point1] to [3.Point 3] (HRM1000, HRM1500, HRM1500 Live) or
[5.Point 5] (HRM2500, HRM2500 Live)
You can congure 3 start points(HRM1000,
HRM1500, HRM1500 Live) or 5 start
points(HRM2500, HRM2500 Live).
You can test that the lawnmower reach each start
points according to settings.
NOTE:
- Perform this test when the lawnmower is connected
to the docking station.
1
Select a point from 1 to 3 or 5 which you
want to test and press the H button.
2
Conrm the value of the selected point
settings.
3
Close the control panel cover.
The lawnmower starts to the selected start
point.
When the test is correctly nished, the
lawnmower rolls slowly from side to side
showing the minimum and maximum exit
angle, and a beep sound is emitted from the
lawnmower.
4
Press the manual STOP button.
The control panel cover pops up.
The message “Do you want to modify the
start point?” appears on the display.
5
Select [Yes] or [No] to the question and
press H button.
If you select [Yes], Start point screen
appears. You can modify the settings of the
tested start point.
If you select [No], the previous screen
appears.
NOTE:
- For details on the start point settings,
see “2. Setting the start points” (M
page 34).
Menu screen
To Next Page
