23. Honda Smart Card Key System
SYSTEM LOCATION································· 23-2
SERVICE INFORMATION ························· 23-3
SYSTEM DIAGRAM·································· 23-4
Honda Smart Card Key REGISTRATION
PROCEDURE ············································· 23-5
Honda Smart Card Key System EMERGENCY
MODE ························································ 23-7
DIAGNOSTIC CODE INDICATION ··········· 23-8
TROUBLESHOOTING ····························· 23-10
TEST HARNESS CONNECTION············· 23-17
Honda Smart Card Key INDICATOR ····· 23-18
HANDLE LOCK MODULE······················· 23-19
LED HOLDER ·········································· 23-28
RF UNIT··················································· 23-28
LF ANTENNA·········································· 23-30
SEAT/CONSOLE BOX LOCK RELEASE
BUTTON·················································· 23-32
CONSOLE BOX LOCK RELEASE
ACTUATOR············································· 23-32
SEAT LOCK RELEASE ACTUATOR ······· 23-34
ANSWER BACK RELAY ························· 23-36
ANSWER BACK DIODE·························· 23-36
