Honda Smart Card Key System
23-3
SERVICE INFORMATION
GENERAL
• When checking the Honda Smart Card Key System, follow the steps in the troubleshooting flow chart (page 23-10).
• Keep the card key away from the other card key when using it. The jamming of the key code signal may occur and the
proper operation of the system will be obstructed.
• The Honda Smart Card Key has built-in electronic part. Do not drop or strike the card key against a hard object, and do
not leave the card key on the dashboard in the car, etc. where the temperature will rise. Do not leave the card key in the
water for a prolonged time such as by washing the clothes.
• The handle lock module as well as the Honda smart card key must be replaced if all key have been lost.
• Once the new Honda Smart Card Key is registered, it is not usable for other vehicle.
• The handle lock module can store up to four card key codes. (The four card keys can be registered.)
• Do not modify the Honda Smart Card Key System as it can cause the system failure. (The engine cannot be started.)
• For ignition system inspection (page 20-5).
TORQUE VALUES
TOOLS
Actuator screw 0.7 N·m (0.1 kgf·m, 0.5 lbf·ft)
LF antenna screw 1.0 N·m (0.1 kgf·m, 0.7 lbf·ft)
Seat/console box lock release button screw 1.0 N·m (0.1 kgf·m, 0.7 lbf·ft)
Inspection adaptor
07XMZ-MBW0101
ECM test harness 21P
070MZ-GEV0100
ECM test harness 33P
070MZ-MCA0100
Test probe
07ZAJ-RDJA110
