Honda Shadow Phantom 750 User Manual

9 lbf·ft (12 N·m , 1.2 kgf·m)
type
viscosity
(weight)
SAE 80
LEFT REAR
(1)
(2)
(1) oil fill cap
(2) oil fill hole
hypoid gear oil
98
Oil Recommendation
Checking & Adding Oil
Final Drive Oil
Servicing Your Honda
Safety PrecautionsRefer to on page .
Place the motorcycle on its side stand
on a firm, level surface.
Remove the oil fill cap ( ).
Check the oil level. It should be flush
with the lower edge of the oil fill hole
().
If the level is low, check for leaks. Add
the recommended oil through the oil fill
hole until it reaches the lower edge of
the opening.
Install the oil fill cap and tighten to the
specified torque:
1.
2.
3.
4.
5.
2
60
1
１０／０９／０２ １１：３５：１８ ３１ＭＦＥ６４０ ０１０７

Honda Shadow Phantom 750 Specifications

General

Engine Type	745cc liquid-cooled 52-degree V-twin
Bore and Stroke	79mm x 76mm
Compression Ratio	9.6:1
Transmission	Wide-ratio five-speed
Final Drive	Shaft
Front Suspension	41mm fork; 4.6 inches travel
Rear Suspension	Dual shocks with five-position spring-preload adjustability; 3.5 inches travel
Front Brake	Single 296mm disc with twin-piston caliper
Rear Brake	Drum
Front Tire	120/90-17
Rear Tire	160/80-15
Rake	34°
Wheelbase	64.6 inches
Seat Height	25.8 inches
Curb Weight	549 pounds
Trail	6.3 inches
Fuel Capacity	3.7 gallons
Induction	PGM-FI with automatic enrichment circuit, one 34mm throttle body
