3.70 US gal (14.0 )
(3)
(2)
(3) filler neck(1) ignition key
(2) fuel fill cap
(1)
79
Refueling Procedure
Fuel Capacity
Fuel
Servicing Your Honda
Safety Precautions
Never use stale or contaminated gasoline
or an oil/gasoline mixture. Avoid getting
dirt, dust, or water in the fuel tank.
Refer to on page .
Fuel tank capacity, including reserve:
The tank should be refilled as soon as
possible when the fuel reserve indicator
comes on.
Insert the ignition key ( ) in the fuel
fill cap ( ) and turn it clockwise.
(cont’d)
1.
60
1
2
１０／０９／０２ １１：３２：５８ ３１ＭＦＥ６４０ ００８８

Honda Shadow Phantom 750 Specifications

General

Engine Type	745cc liquid-cooled 52-degree V-twin
Bore and Stroke	79mm x 76mm
Compression Ratio	9.6:1
Transmission	Wide-ratio five-speed
Final Drive	Shaft
Front Suspension	41mm fork; 4.6 inches travel
Rear Suspension	Dual shocks with five-position spring-preload adjustability; 3.5 inches travel
Front Brake	Single 296mm disc with twin-piston caliper
Rear Brake	Drum
Front Tire	120/90-17
Rear Tire	160/80-15
Rake	34°
Wheelbase	64.6 inches
Seat Height	25.8 inches
Curb Weight	549 pounds
Trail	6.3 inches
Fuel Capacity	3.7 gallons
Induction	PGM-FI with automatic enrichment circuit, one 34mm throttle body
