General| Engine Type | 745cc liquid-cooled 52-degree V-twin |
|---|---|
| Bore and Stroke | 79mm x 76mm |
| Compression Ratio | 9.6:1 |
| Transmission | Wide-ratio five-speed |
| Final Drive | Shaft |
| Front Suspension | 41mm fork; 4.6 inches travel |
| Rear Suspension | Dual shocks with five-position spring-preload adjustability; 3.5 inches travel |
| Front Brake | Single 296mm disc with twin-piston caliper |
| Rear Brake | Drum |
| Front Tire | 120/90-17 |
| Rear Tire | 160/80-15 |
| Rake | 34° |
| Wheelbase | 64.6 inches |
| Seat Height | 25.8 inches |
| Curb Weight | 549 pounds |
| Trail | 6.3 inches |
| Fuel Capacity | 3.7 gallons |
| Induction | PGM-FI with automatic enrichment circuit, one 34mm throttle body |
