Honda Shadow Phantom 750 User Manual

(2)
(1) digital clock
(2) odometer/tripmeter/digital clock
select and reset button
(1)
22
Digital Clock
Gauges, Indicators & Displays
Instruments & Controls
Shows hour and minute. To adjust the time,
proceed as follows:
Turn the ignition switch ON.
Show the digital clock ( ).
Push and hold the odometer/tripmeter/
digital clock select and reset button ( )
for more than 2 seconds. The clock will
be set in the adjust mode with the hour
display flashing.
1.
2.
3.
1
2
１０／０９／０２ １１：２５：５７ ３１ＭＦＥ６４０ ００３１

Honda Shadow Phantom 750 Specifications

General

Engine Type	745cc liquid-cooled 52-degree V-twin
Bore and Stroke	79mm x 76mm
Compression Ratio	9.6:1
Transmission	Wide-ratio five-speed
Final Drive	Shaft
Front Suspension	41mm fork; 4.6 inches travel
Rear Suspension	Dual shocks with five-position spring-preload adjustability; 3.5 inches travel
Front Brake	Single 296mm disc with twin-piston caliper
Rear Brake	Drum
Front Tire	120/90-17
Rear Tire	160/80-15
Rake	34°
Wheelbase	64.6 inches
Seat Height	25.8 inches
Curb Weight	549 pounds
Trail	6.3 inches
Fuel Capacity	3.7 gallons
Induction	PGM-FI with automatic enrichment circuit, one 34mm throttle body
