Power open hot water zone valve
C Common wire (optional)
W Heat relay
R Power
Notes
Thermostat C wire
is optional for this
application. C wire required
if Homekit is used.
Set the R Jumper Switch
on the wall plate to R
Two wire powered humidifier, dehumidifier, ventilator
U1 IAQ relay
U2 IAQ relay
Notes
Set the Jumper
Switch on the wall plate to
2 Wire
Single wire non-powered humidifier, dehumidifier, ventilator, or
dehumidification with low speed fan
U1 IAQ relay Notes
Set the Jumper Switch on
the wall plate to 1 Wire
