Honeywell Home T5 Smart Thermostat User Manual

10 11
11 Insert the wall anchors
It is recommended that you use the
wall anchors included in the box to
mount your thermostat.
You can use the UWP to mark where
you want to place the wall anchors.
a) Level the wall plate.
b) Mark the location of the wall
anchors using a pencil.
c) Drill the holes.
d) Insert wall anchors.
e) Make sure anchors are flush with
wall.
Tip: Use a 7/32 (5.6 mm) drill bit.
10 Bundle and insert wires through
the UWP
Pull open the UWP and insert the
bundle of wires through the back of
the UWP.
Make sure at least 1/4-inch
(6.4 mm) of each wire is exposed for
easy insertion into the wire terminals.

Honeywell Home T5 Smart Thermostat Specifications

General

Model	T5
Type	Smart Thermostat
Connectivity	Wi-Fi
Energy Star Certified	Yes
Voltage	24V
Remote Control	Yes, via Honeywell Home App
Warranty	1-year limited warranty
Compatibility	Amazon Alexa, Apple HomeKit, Google Assistant
Display	Touchscreen
Programmable	7-Day Flexible Scheduling
Features	Geofencing, Smart Alerts
Operating Modes	Heat, Cool, Auto, Off
Energy Saving Features	Energy Star Certified
Dimensions	4.06 x 4.06 x 1.06 inches
Power Source	C-Wire
