Honeywell Home T5 Smart Thermostat User Manual

8 9
7 Record if you have wires in the following terminals
Do not include jumpers as a part of your count. The thermostat does not need
jumpers.
Terminal Wire Color
R
Rh
Rc
8 Write down the color of the wires
Check mark the wires that are connected to terminals. Next to the check mark,
write down the color of the wire. Do not include jumpers as a part of your count.
Check all that apply (Not all will apply):
Terminal Wire Color
Y
Y2
G
C
Terminal Wire Color
A or L/A
O/B
W2 or AUX
E
W
K
Required
S and U terminals are not supported with this thermostat.
If there are wires in terminals that are not listed, you will need additional wir-
ing support. Visit honeywellhome.com to find out if the thermostat will work
for you.

Honeywell Home T5 Smart Thermostat Specifications

General

Model	T5
Type	Smart Thermostat
Connectivity	Wi-Fi
Energy Star Certified	Yes
Voltage	24V
Remote Control	Yes, via Honeywell Home App
Warranty	1-year limited warranty
Compatibility	Amazon Alexa, Apple HomeKit, Google Assistant
Display	Touchscreen
Programmable	7-Day Flexible Scheduling
Features	Geofencing, Smart Alerts
Operating Modes	Heat, Cool, Auto, Off
Energy Saving Features	Energy Star Certified
Dimensions	4.06 x 4.06 x 1.06 inches
Power Source	C-Wire
