Page #10 background image
EC7830A, RM7830A, EC7850A, RM7850A 7800 SERIES RELAY MODULES
66-1092—06 10
a
See Table 2.
b
2000 VA maximum connected load to relay module.
c
Honeywell has tested this output at 9.8A at PF = 0.5, 58.8A inrush for 100,000 cycles
(EN298 approval does not require this test).
d
Total load current, excluding Burner/Boiler Motor and Firing Rate Outputs cannot exceed 5A, 25A inrush.
e
Total load current, excluding Burner/Boiler Motor and Firing Rate Outputs cannot exceed 5A, 25A inrush for 250,000 cycles.
f
Can also be 24 Vac, 3A at PF = 0.5.
g
220/240 Vac to 120 Vac, 10 VA stepdown transformer (not provided) must be used to drive the shutter.
WARNING
Fire or Explosion Hazard.
Can cause severe injury, death, or property
damage.
Close all manual fuel shutoff valves before starting this
test to prevent an explosion.
Table 4. EC7850A/RM7850A Terminal Ratings.
Terminal
No. Abbreviation Description RM7850A (120 Vac) EC7850A (220/230/240 Vac)
G—
Flame Sensor Ground.
a
——
Earth G
Earth Ground.
a
——
N Line Voltage Common (Neutral)
3 AL Alarm (Normally Open) 1A, 10A inrush for 5000
cycles.
1A, 10A inrush for 5000
cycles.
4 L1 Line Voltage Supply (L1) 120 Vac (+10%/-15%), 50/60
Hz (±10%).
b
220/230/240 Vac (+10%/-
15%), 50/60 Hz (±10%).
b
5 FAN Burner/Blower Motor
4A at PF = 0.5, 20A inrush.
c
4A at PF = 0.5, 20A inrush.
6 RT Limits and Burner Control 1 mA. 1 mA.
7 LD2 Airflow Switch Input 5A. 5A.
8 pv1 Pilot Valve 1 (Interrupted)
4A at PF = 0.5, 20A inrush.
d
4A at PF = 0.5, 20A inrush.
e
9 MV Main Fuel Valve
4A at PF = 0.5, 20A inrush.
d
4A at PF = 0.5, 20A inrush.
e
10 IGN Ignition 2A at PF = 0.2. 2A at PF = 0.2.
F (11) Flame Signal 60 to 220 Vac, current limited. 136 to 220 Vac, current limited.
12 HI Firing Rate High Fire
0.5A at PF = 0.5.
f
0.5A at PF = 0.5.
f
13 COM Firing Rate Common
0.5A at PF = 0.5.
0.5A at PF = 0.5.
f
14 MOD Firing Rate Modulate
0.5A at PF = 0.5.
f
0.5A at PF = 0.5.
f
15 LO Firing Rate Low Fire
0.5A at PF = 0.5.
f
0.5A at PF = 0.5.
f
16 Alarm (Normally Closed) 1A, 10A inrush for 5000
cycles; carry 5A for 250,000
cycles.
1A, 10A inrush for 5000
cycles; carry 5A for 250,000
cycles.
17 ES2 Preignition Interlock Input 1 mA. 1 mA.
18 ES1 Low Fire Switch Input 1 mA. 1 mA.
19 ES3 High Fire Switch Input 1 mA. 1 mA.
20 LOS Lockout Input 1 mA. 1 mA.
21 PV2 Pilot Valve 2 (Intermittent)
4A at PF = 0.5, 20A inrush.
d
4A at PF = 0.5, 20A inrush.
e
22 SHTR Shutter Shutter drive for dynamic
self-check flame sensor.
Shutter drive for dynamic
self-check flame sensor.
g
