Honeywell 7800 SERIES

65-0120—1 28
TABLE 3—SEQUENCE STATUS DISPLAY INFORMATION, SEE FIG. 23.
RM7838B
OPERATION
Burner Sequence LEDs Energized
INITIATE minutes:seconds
↕selectable—message
POWER, PILOT, FLAME, MAIN AND ALARM
INITIATE HOLD: AC
(AC Freq/Noise)
POWER, PILOT, FLAME, MAIN AND ALARM
INITIATE HOLD: AC
(AC Line Dropout)
POWER, PILOT, FLAME, MAIN AND ALARM
INITIATE HOLD: AC
(AC Frequency)
POWER, PILOT, FLAME, MAIN AND ALARM
INITIATE HOLD: AC
(Low Line Voltage)
POWER, PILOT, FLAME, MAIN AND ALARM
STANDBY
↕selectable —message
POWER, PILOT, FLAME, MAIN AND ALARM
STANDBY HOLD: REM
(Remote Control)
POWER, PILOT, FLAME, MAIN AND ALARM
STANDBY HOLD: F/G
(Flame Detected)
POWER, PILOT, FLAME, MAIN AND ALARM
STANDBY HOLD: T20
(Preignition ILK)
POWER, PILOT, FLAME, MAIN AND ALARM
STANDBY HOLD: T7
(Lockout ILK)
POWER, PILOT, FLAME, MAIN AND ALARM
PURGE HOLD: T19
(High Fire Switch)
POWER, PILOT, FLAME, MAIN AND ALARM
PURGE DELAY: T19
(High Fire Jumprd)
POWER, PILOT, FLAME, MAIN AND ALARM
PURGE HOLD: TEST
(Run/Test Switch)
POWER, PILOT, FLAME, MAIN AND ALARM
PURGE DELAY: T18
(Low Fire Jumprd)
POWER, PILOT, FLAME, MAIN AND ALARM
PURGE HOLD: F/G
(Flame Detected)
POWER, PILOT, FLAME, MAIN AND ALARM
PURGE HOLD: T18
(Low Fire Switch)
POWER, PILOT, FLAME, MAIN AND ALARM
PURGE minutes:seconds
↕selectable—message
POWER, PILOT, FLAME, MAIN AND ALARM
PURGE HOLD: T7
(Lockout ILK)
POWER, PILOT, FLAME, MAIN AND ALARM
PURGE HOLD: T21
Start Switch
POWER, PILOT, FLAME, MAIN AND ALARM
PILOT IGN minutes:seconds
↕selectable—message
POWER, PILOT, FLAME, MAIN AND ALARM
PILOT HOLD: TEST
(Run/Test Switch)
POWER, PILOT, FLAME, MAIN AND ALARM
MAIN IGN minutes:seconds
↕selectable—message
POWER, PILOT, FLAME, MAIN AND ALARM
RUN
↕selectable—message
POWER, PILOT, FLAME, MAIN AND ALARM
RUN
↕selectable—message
POWER, PILOT, FLAME, MAIN AND ALARM
RUN LOWFIRE: TEST
(Run/Test Switch)
POWER, PILOT, FLAME, MAIN AND ALARM
RESET/ALARM TEST
↕selectable—message
POWER, PILOT, FLAME, MAIN AND ALARM
For additional sequence status information when an Expanded Annunciator is connected to the Relay Module, see Table 15.
STANDBY
(Burner Switch)
POWER, PILOT, FLAME, MAIN AND ALARM
STANDBY HOLD: T6
(Expanded Annunciator hold message)
POWER, PILOT, FLAME, MAIN AND ALARM
STANDBY HOLD: T6
(Circuit Fault)
POWER, PILOT, FLAME, MAIN AND ALARM
