65-0120—1 8
Fig. 5—Ultraviolet detectors
RM7838B
SPECIFICATIONS
1/2-14 NPSM
INTERNAL THREADS
2
2 (51)
COLLAR WITH
1–11-1/2 NPSM
INTERNAL
THREADS
1
1
DIN APPROVED C7035A1064 HAS 1-11 BSP.P1 INTERNAL THREADS.
DIN APPROVED C7035A1064 HAS 1/2-14 BSP-F INTERNAL THREADS.
MODEL AVAILABLE WITH 12 FOOT [3.66 METER] LEADWIRES.
2
3
INSERTION DEPTH
6 FOOT
[1.83 METER]
LEADWIRES (2)
3
M1945A
2-5/8 (67)
1-1/2
(38)
31/32
(25)
4-1/8 (105)
1-3/16
(30)
C7035
COLLAR WITH 1/2-14 NPSM
INTERNAL THREADS
4 (102)
6 FOOT (1.83 METER)
LEADWIRES (2)
M1943A
MODEL AVAILABLE WITH 24 FOOT (7.32 METER) LEADWIRES.
MODELS AVAILABLE WITH SPUD CONNECTOR (1/2-14 NPSM INTERNAL
THREADS) INSTEAD OF CLAMP TYPE CONNECTOR.
1
2
1
2
3-1/2 (89)
1-1/16
(27)
C7027
MOUNTING BRACKET
6 FOOT [1.83 METER]
LEADWIRES (2)
M1944A
3-5/8 (92)
1/2
(13)
9/16
(14)
7/8
(22)
3/8
(10)
1-27/64
(36)
C7044
15/16 [24] DIA.
2 (51)
1 (25)
1 INCH NPT
15/16–18 UNC
(2 EACH)
M5084
2-1/2
(64)
6-7/32)
(158)
6-19/32
(168)
2-5/32
(55)
11-13/16 (300)
7-13/16 (198)
1-27/32
(47)
5-13/16 (147)
5-13/16
(147)
C7076D
