Honeywell ALERTON ACM-AXM User Manual

Installation and Operations Guide
|
Initial firmware and operator workstation setup
© Honeywell. All Rights Reserved. LT-VLXEXPAXMIOG Rev. 01
57
Note Alerton Standard object templates (99992002.obt and 99992005.obt)
allow you to view the backup mode configuration for binary and analog outputs.
Table 12 Backup mode AVs for AOs and BOs
Backup mode AV
EXP-1048 outputs
AXM-1048 o utputs
EXP-10120 o utputs
AXM-10120outputs
e 600 EXP e , BO 0 EXP e , BO 0
e 601 EXP e , BO 1 EXP e , BO 1
e 602 EXP e , BO 2 EXP e , BO 2
e 603 EXP e , BO 3 EXP e , BO 3
e 604 EXP e , AO 0 EXP e, BO 4
e 605 EXP e , AO 1 EXP e , BO 5
e 606 EXP e , AO 2 EXP e, BO 6
e 607 EXP e , AO 3 EXP e, BO 7
e 608 EXP e , AO 4 EXP e, BO 8
e 609 EXP e , AO 5 EXP e, BO 9
e 610 EXP e , AO 6 EXP e , BO 10
e 611 EXP e , AO 7 EXP e, BO 11
