B KRA 405
Rev 6, June 2003 IM 006-00104-0006.dwd Page 1-7
1.4.1.B.3 The indicator with a gray faceplate and 5 volt lighting is P/N 066-03031-0002,
P/N 066-03044-0002.
1.4.1.B.4 The indicator with a gray faceplate and 28 volt lighting is P/N 066-03031-0003,
P/N 066-03044-0003.
1.4.1.B.5 The indicator with a black faceplate and NVG lighting is P/N 066-03031-0004,
P/N 066-03044-0004.
1.4.1.C Bendix/King KA 54A Radar Altimeter Antenna (2 each), P/N 071-01501-0000.
1.4.1.D Bendix/King KRA 405 Radar Altimeter R/T Installation Kit (050-01391-0000)
which includes:
050-01391-0000 INSTALLATION KIT 3
---------------------------------------------------------------
SYMBOL PART NUMBER FIND NO DESCRIPTION UM -0000
---------------------------------------------------------------
030-02211-0000 CONNECTOR EA 1.00
057-02029-0007 LABEL EA 1.00
071-04003-0000 MTG RACK 3 INCH EA 1.00
P/N 030-02211-0000, connector, vendor part numbers:
Cannon KPT06B18-32SW
Burndy BT06AC18-32SW
Array PW06B18-32SW
Amphenol PT06A18-32SW(SR)
1.4.1.E Bendix/King KNI 415, KNI 416 Radar Altimeter Indicator Installation Kit (either
050-01401-0000 for black units or 050-01401-0001 for gray units) which in-
cludes:
050-01401-0000 INSTL KIT BLK PLT AA
050-01401-0001 INSTL KIT GRY PLT AA
----------------------------------------------------------------------
SYMBOL PART NUMBER FIND NO DESCRIPTION UM -0000 -0001
----------------------------------------------------------------------
030-02210-0006 CONN 19P F Y OLV EA 1.00 1.00
057-02029-0008 LABEL EA 1.00 1.00
057-02029-0009 LABEL EA 1.00 1.00
073-00044-0001 PLATE MOORING EA 1.00 1.00
073-00045-0000 ADAPTOR PLATE EA 1.00 .
073-00045-0001 ADAPTOR PLATE EA . 1.00
089-05115-0012 SCR, MACH, 6-32, F EA 4.00 .
089-06461-0012 SCR FHP 6-32X3/4 EA . 4.00
P/N 030-02210-0006, connector, vendor part numbers:
Cannon KPT06B14-19SY
Burndy BT06AC14-19SY
