Honeywell C6097A User Manual

C6097 · Edition 01.24
EN-5
1 2 3
4
NC
1
COM
3
NO
NO
2
N
NO
2
NC
1
COM
3
L1
N
NC
1
COM
3
NO
NC
2
N
NO
2
NC
1
COM
3
L1
N
8.7 Red/green LED for 24VDC/AC or 110–
230VAC
24V DC, I = 16mA; 24V AC, I = 8mA,
Order No.: 32003048-003/U.
110 to 230V AC, Order No.: 32003049-003/U.
1 2 3
4
NC
1
COM
3
NO
2
N
NO
2
1 NC
3 COM
+
–
8.8 Cover for auto reset
Order No.: 32003040-003/U.
8.9 Weather protection cover
B
A
C
D
G
E
F
In the case of outdoor installation, the weather pro-
tection cover provides permanent protection against
condensation and weathering of housing parts.
The weather protection cover is made of 1mm
(0.04") thick stainless steel.
Installation position: vertical, with the cable gland
pointing downwards.
Scope of delivery:
A 1 x cover, 100 x 100 x 100mm
B 2 x M4 x 16 screws
C 4 x nuts
D 2 x washers
E 2 x cap nuts
F 1 x filter pad (1/8"port)
G 1 x pull-tab plug
Order No.: 32003050-003/U
