Honeywell CIPer 30 Installation Instructions

CIPer
TM
MODEL 30 EXPANSION IO MODULES - INSTALLATION INSTRUCTIONS
31-00319-02
2
Specifications
Electrical
Voltage rating
20-30 VAC, 50/60Hz
Power consumption
100 VA for CIPer 30 EXPIO device and all connected loads.
Note:
Power consumption is based on the sum of the VA rating for each
controller and should not exceed 100VA. If additional modules are
required, then they must be powered from a separate transformer.
WEB-O9056H:
− With all binary output loads connected - 207VA
− Without any binary output loads connected – 35VA
WEB-O3022H:
− With all binary output loads connected - 87VA
− Without any binary output loads connected – 15VA
Digital Output voltage rating
20 to 30 VAC @ 50/60 Hz
Digital Output type/ rating
Solid-State Relay, 1.5A
Continuous, 3.5A inrush for 100 ms
Environmental
Ambient temperature
-4 to 131F (-20 to 55C)
Storage temperature
-4 to 150F (-20 to 65C)
Humidity
5% to 95% non-condensing
Differential pressure sensor
range (VAV model)
0-2” WC (0 to 374 Pa), 32 to 122F (0 to 55C)
Purpose of Control
Operating Control, Open Energy Management Equipment
Pulse Inputs
100Hz max, minimum duty cycle: 5 ms ON / 5 ms OFF.

Honeywell CIPer 30 Specifications

General

Brand	Honeywell
Model	CIPer 30
Category	Controller
Language	English
