CT47 Mobile Computer Series User Guide 103
Note: To learn about changing the symbology settings, see Change the Scanner Settings on
page 36.
N6803 FlexRange Imager
The depth of field measurements used the following parameters:
• Distances are measured from the front of the Imager.
• +23 °C (+73 °F), 200 lux for guaranteed, 200 lux for typical.
• Photographic quality codes.
Note: Time to Read and Depth of Field will be impacted if the barcode symbol is at the edge
of the image.
Guaranteed Specs
Interleaved 2 of 5 Enabled Digimarc Disabled
Matrix 2 of 5 Disabled TLC 39 Disabled
MSI Disabled
Telepen Disabled
Trioptic Disabled
UPC/EAN Enabled
UPC-A Enabled
UPC-E Enabled
1D Symbologies 2D Symbologies Postal Codes
Default Default Default
Focus Standard Range
Symbology Near Distance Far Distance
5 mils Code 39 mm 138 365
in. 5.43 14.4
10 mils Data Matrix mm 152 387
in. 6 15.23
10 mils Code 39 mm 94 1198
in. 4 47.2
13 mils UPC-A mm 68 1437
in. 3 57
15 mils Code 128 mm 66 1571
in. 3 62
1
Minimum distance depends on the length of the barcode.
2
Typical code wide to narrow elemental ratio is 3:1. Minimum 100 mils code height of 3 inches.
