02/2011
E
N
G
L
I
S
H
74-Digital protocols
First protocol
7411
51 128
5 = SECOM3
7 = VOCAL
9 = CONTACT ID
9
First subscriber number
7412
51 249
Up to 8 hexadecimal digits
(e.g. 0000XXXX for 4-digit numbers)
00009999
75-Telephone numbers
For each phone number, it is possible to select the network, address number or IP address, plus supported protocol,
with the following constraints:
The telephone number parameters only apply to PSTN, GSM Voice and GSM data.
The IP Address parameters only apply to GPRS and Ethernet.
Number
At most 21 characters
(including * ; , and #. + should be replaced by 00)
-
IP address: port number
The IP address consists of 4 groups of 3 digits (e.g. xxx.xxx.xxx.xxx:yyy).
-
Selected APN
0 = First
1 = Second
G = 0, H = 1
The address codes for telephone numbers A to H are according to the following table.
A
B
C
D
E
F
PSTN
PSTN
PSTN
PSTN
GSM
GSM DATA
Number
7511
61 240
7521
62 242
7531
63 244
7541
64 246
7551
65 248
7561
66 240
G
H
GPRS
GPRS
IP address
7572
67 238
7582
68 230
Selected APN
7573
67 420
7583
68 422
76-Cyclic Tests
Test 1 period
7611
41 127
0 to 44639 in minutes (24h = 1440 min)
-
Test 1 start hour
7612
41 426
0 to 23
-
Test 1 start minute
7613
41 529
0 to 59
-
77-Incoming Calls
Pick up line
7701
15 328
0 = Never
1 = After n rings
2 = Double call
1
Number of rings
7702
15 122
2 to 12
8
Call in maintenance
7703
15 823
0 = authorised
1 = locked
0
6-Receivers (Types A25 and A27): Wired panel output or X10 address
Activate wired extension
610
03314111397
1B 0 10000002
-
Activate X10 address
620
03314111397
19 0 HHUU
HH: 2-digit number for “house” letter (00 for A)
UU: “unit” number minus 1 (00 for 1, 0A for 11)
0000
This should also be followed by the advanced command: type in parameter address 0297093 and validate
