DR4300 Circular Chart Recorder
92 DR4300 Circular Chart Recorder Product Manual 4/00
Lower Display
Prompt
Upper Display
Range of Setting
or Selection
Parameter
Definition
INP EU
NONE [factory setting]
CuFt
GAL
CuMt
LITR
AcFt
HMTR
ENGINEERING UNITS OF INPUT SIGNAL
NONE—Disables EU conversions and disables TOT EU and
TOT DP functions.
Cubic Feet
Gallons
Cubic Meters
Liters
Acre-Feet
Hectare-Meters
RATE
SEC [factory setting]
MIN
HOUR
DAY
MDAY
RATE OF INTEGRATION—This parameter is used to select
the desired rate of integration.
SECOND—EU (Engineering Units) per second
MINUTE—EU per minute
HOUR—EU per hour
DAY—EU per DAY
MDAY—Millions of units per day
TOT EU
NONE [factory setting]
CuFt
GAL
CuMt
LITR
AcFt
HMTR
ENGINEERING UNITS OF TOTALIZED VALUE
NONE—Disables EU conversions.
Cubic Feet
Gallons
Cubic Meters
Liters
Acre-Feet
Hectare-Meters
TOT DP
8888 [factory setting]
888.8
88.88
TOTALIZED VALUE DECIMAL PLACES—This parameter is
used to select the number of decimal places of the displayed
TOTAL value. This selection will be overridden if the SCALER
selection is not equal to 1.
SCALER
1 (displays as E0)
[factory setting]
10 (displays as E1)
100 (displays as E2)
1000 (displays as E3)
1E4 (displays as E4)
1E5 (displays as E5)
1E6 (displays as E6)
1E7 (displays as E7)
1E8 (displays as E8)
TOTALIZER SCALE FACTOR—The totalizer displays the
current totalized flow value (up to six digits maximum). The
scaling factor selected here is applied to the totalized value
when it is displayed.
1E4 equals 1 times 10
4
(10,000)
1E5 equals 1 times 10
5
(100,000)
1E6 equals 1 times 10
6
(1,000,000)
1E7 equals 1 times 10
7
(10,000,000)
1E8 equals 1 times 10
8
(100,000,000)
