Honeywell DR4300 - Figure 2-4 Panel Mounting Recorder with NEMA4 or Heavy Duty Door

Installation
3/00 DR4300 Circular Chart Recorder Product Manual 19
Notch
Pan Head Screw
8-32 x 1/2 inch
Hex Head Bolt
1/4-20 x 3/8 inch
Hex Head Bolt
1/4-20 x 3/4 inch
Bracket
Side View
NOTE: Mounting brackets and attaching hardware are included in kit 30755065-502;
panel gasket supplied in kit 51197657-501.
Figure 2-4 Panel Mounting Recorder with NEMA4 or Heavy Duty Door
