DR4300 Circular Chart Recorder
DR4300 Circular Chart Recorder Product Manual 3/0042
TB5
Load
0-600 Ohms
Current
Output
or
Auxiliary
Output
_
+
7
TB2
TB1
7
TB2
TB1
Main PCA
Pen 2
Main PCA
Pen 1
24824
Figure 2-16 Current Output Wiring
