Appendix B - Available 10-inch Charts
4/00 DR4300 Circular Chart Recorder Product Manual 203
B. Available 10-inch Charts
B.1 Single Range Charts
Table B-1 lists the chart part numbers for the available 10-inch single range charts.
✔ indicates the chart is used in Table 3-2 configurations.
Table B-1 10-inch Single Range Chart Part Numbers
Chart Type Range Units 24 HR
P/N 24001660-XXX
7 DAY
P/N 24001661-XXX
B Thermocouple
0 to 1800 C 135
J Thermocouple
–18 to 425 C 028 028
–45 to +150 C 027 027
–50 to +300 F 019 019
0 to 150 C 070 ✔ 070 ✔
0 to 200 F 114 ✔
0 to 250 C 024 ✔ 024 ✔
0 to 300 F 002 ✔ 002 ✔
0 to 300 C 062 ✔ 062
0 to 400 F 012 ✔ 006
0 to 400 C 063 ✔ 063
0 to 500 F 013 ✔ 007 ✔
0 to 600 F 008 ✔
0 to 800 F 014 ✔ 009 ✔
0 to 1000 F 015 ✔ 010 ✔
0 to 1200 F 004 ✔ 011 ✔
0 to 1600 F 018 ✔ 018 ✔
10 to 340 C 057 ✔ 057 ✔
10 to 76 C 030 030
50 to 1400 F 029 029
50 to 650 F 056 056
100 to 260 C 094
150 to 750 F 150
810 to 910 F 230
