DR4300 Circular Chart Recorder
204 DR4300 Circular Chart Recorder Product Manual 4/00
Chart Type Range Units 24 HR
P/N 24001660-XXX
7 DAY
P/N 24001661-XXX
K Thermocouple
–18 to 1320 C 031 031
0 to 200 C 086 ✔
0 to 400 F 053 ✔ 053
0 to 400 C 064 ✔ 064
0 to 500 C 205 ✔
0 to 600 C 059 ✔ 059
0 to 800 C 060 ✔ 060
0 to 1000 F 007 ✔ 016 ✔
0 to 1000 C 049 ✔ 049 ✔
0 to 1200 F 006 ✔ 012 ✔
0 to 1200 C 065 ✔
0 to 1600 F 016 ✔ 013 ✔
0 to 2000 F 005 ✔ 014 ✔
0 to 2400 F 009 ✔ 015 ✔
800 to 1000 F 227
R Thermocouple
0 to 1600 C 017 ✔ 017
0 to 2500 F 025 ✔ 025 ✔
30 to 2900 F 032 ✔ 032 ✔
800 to 2500 C 089
S Thermocouple
0 to 1600 C 066
0 to 3000 F 147 ✔ 147 ✔
T Thermocouple
–250 to +150 F 042 ✔ 042 ✔
–130 to +410 F 033 ✔ 033 ✔
–100 to +100 C 069 069 ✔
–90 to +210 C 034 ✔ 034 ✔
0 to 100 C 100
0 to 150 C 103 ✔ 201 ✔
0 to 300 C 079
+75 to –200 C 058 ✔
+125 to –105 098
W5W26 Thermocouple
0 to 1800 C 157 ✔
