DR4300 Circular Chart Recorder
194 DR4300 Circular Chart Recorder Product Manual 4/00
Basic recorder components without options
Figure 9-3 is an exploded view of the recorder. Table 9-3 is a list of the associated part numbers.
1
2
3
24090A
4
5
Figure 9-3 Recorder Components
