DR4300 Circular Chart Recorder
222 DR4300 Circular Chart Recorder Product Manual 4/00
Lower Display
Prompt
Upper Display
Range of Setting
or Selection
Parameter
Definition
.
.
.
Continue to configure ramp segments (odd-numbered) and soak segments (even-numbered) through
Segments 23 and 24.
.
.
.
SG23RP
0 to 99 hours:0 to 59 min
(if RPUNIT = TIME)
or
0 to 999 degrees per minute
or hour (if RPUNIT = EU-M
or EU-H)
[factory setting = 0.00]
SEGMENT 23 RAMP VALUE—Enter the ramp time or
ramp value for Segment 23.
SG24SP
range depends on setpoint
limits [factory setting = 0]
SEGMENT 24 SETPOINT—Enter the setpoint for
Segment 24.
SG24TI
0 to 99 hours:0 to 59 min
[factory setting = 0]
SEGMENT 24 TIME—Enter the duration for Segment 24
