Appendix C - Setpoint Ramp/Soak
Programming and Operation
4/00 DR4300 Circular Chart Recorder Product Manual 225
Function Press Result
Viewing the Number of
Cycles Left for the
Program
DISPLAY
until you see
Upper Display
input value
Lower Display
REC.X
Number of cycles remaining in the
setpoint program
X = 0 to 99
Ending the Program
When the final segment is completed, the “RUN” in the
lower display either changes to “HOLD” (if configured for
HOLD state), or disappears (if configured for disable of
setpoint programming).
The recorder will operate at the last setpoint achieved by
the program.
Disable Program
SETUP
until you see
Upper Display
SETUP
FUNCTION
until you see
Upper Display
ENAB
or
until you see
Upper Display
DIS
DISPLAY
Exit configuration and program is disabled.
