Input and Output Calibration for Recorder with Display
4/00 DR4300 Circular Chart Recorder Product Manual 143
Table 5-1 Voltage and Resistance Equivalents for 0 % and 100 % Range Values
Sensor Type PV Input Range Range Values*
Thermocouples °F °C 0 % 68 °F/20 °C 100 %
B
105 to 3300 41 to 1816 0 mV 13.769 mV
E
–454 to 1832 –270 to 1000 –9.835 mV 1.192 mV 76.373 mV
E (low)
–200 to 1100 –129 to 593 –6.472 mV 44.555 mV
J
0 to 1600 –18 to 871 –0.886 mV 1.019 mV 50.060 mV
J (low)
20 to 770 –7 to 410 –0.334 mV 22.400 mV
K
–320 to 2500 –196 to 1371 –5.822 mV 0.798 mV 54.856 mV
K (low)
–20 to 1000 –29 to 538 –1.114 mV 22.255 mV
Ni-Ni-Moly
32 to 2500 0 to 1371 –0.000 mV 0.755 mV 71.773 mV
Nicrosil-Nisil
0 to 2372 –17.8 to 1300 –0.461 mV 0.525 mV 47.513 mV
R
0 to 3100 –18 to 1704 –0.090 mV 0.111 mV 20.281 mV
S
0 to 3100 –18 to 1704 –0.092 mV 0.113 mV 17.998 mV
T
–420 to 700 –251 to 371 –6.187 mV 0.789 mV 19.097 mV
T (low)
–200 to 600 –129 to 316 –4.149 mV 15.771 mV
W5W26
0 to 4200 –18 to 2315 -0.234 mV 0.273 mV 37.075 mV
RTD
100 Ω **
100 Ω (low)**
100 Ω (T)***
–300 to 900
–130 to 392
–238 to 482
–184 to 482
–90 to 200
–150 to 250
25.18 Ω
64.30 Ω
38.79 Ω
274.96 Ω
175.84 Ω
195.57 Ω
Milliamps
0 mA to 20 mA 0 mA 20 mA
4 mA to 20 mA 4 mA 20 mA
Millivolts
0 mV to 10 mV 0 mV 10 mV
0 mV to 100 mV 0 mV 100 mV
0 mV to 200 mV 0 mV 200 mV
Volts
0 V to 1 V 0 V 1 V
0 V to 2 V 0 V 2 V
1 V to 5 V 1 V 5 V
0 V to 5 V 0 V 5 V
0 V to 10 V 0 V 10 V
2 V to 10 V 2 V 10 V
*Range values for thermocouples are based on a cold junction temperature of 32 °F (0 °C). These values must be adjusted for the
actual cold junction temperature when using the ambient temperature method for calibrating thermocouple inputs.
** IEC Alpha = 0.00385
*** Alpha = 0.00391
