Configuration, Startup, and Operation
of Recorder with Display
4/00 DR4300 Circular Chart Recorder Product Manual 83
4.3.6 Configuration Procedure
Introduction
The configuration prompts are sequenced in a group/function hierarchy as shown in Figure 4-2. Once you
have set the input switches in SW6 as described in Subsection 4.3.5, configure all the function parameters
that are applicable for your recorder model and application. During configuration some function parameters
will not be displayed if they do not apply to your application. For example, if you set the control group
function “CONTRL” to “DIS”, disabling control, then no other control group prompts will be displayed.
To enter your selections or values, follow the procedure in Table 4-4 and fill in the values or selections on
the worksheet in Subsection 4.3.21. Keep this worksheet as a record of how your recorder was configured.
This procedure tells you the keys to press to get to any set up group (and any associated function parameters
prompt).
Procedure
Follow the procedure listed in Table 4-4 to access the set up groups and function prompts. If you have a
2-pen recorder, be sure to identify individual parameters for each pen and control loop as applicable.
Make sure lock set up group “LOCK” function is set to “NONE” or “CAL.” See Subsection 4.3.19.
Table 4-4 Configuration Procedure
Step Operation Press Result
1
Select Set Up mode
SET
UP
Lets you know you are in the
configuration mode and a set up group
title is being displayed in the lower
display.
INPUT
This is the first set up group title.
2
Select any set up group
SET
UP
• Successive presses of the SET UP
key will display
the other set up group titles shown in the prompt
hierarchy in Figure 4-2.
• You can also use the [▲] [▼] keys to scan the set up
groups in both directions.
• Stop at the set up group title which describes the
group of parameters you want to configure. Then
proceed to the next step.
3
Select a function parameter
FUNC
xxxx
Shows the current value or selection for
the first function prompt of the set up
group that you have selected.
DECMAL
Shows the first function prompt within
the selected set up group.
Example displays show Input group function prompt
“DECMAL” and the value selected.
To Next Page
