Honeywell DR4312 User Manual

Configuration, Startup, and Operation
of Recorder with Display
4/00 DR4300 Circular Chart Recorder Product Manual 85
4.3.7 Input Parameters Set Up Group
Introduction
These are the parameters required to configure the temperature units, decimal location, actuation, high and
low range values in engineering units, bias, filter, and burnout. For a 2-pen recorder, the desired input
channel is displayed on the left side of the operator interface.
Press FUNC
key to select channel.
Input group prompts
Table 4-5 lists all the function prompts in the input set up group.
Press SETUP
key until “INPUT” appears in the lower display.
Press FUNC
key to display the parameters.
Table 4-5 Input Parameter Definitions
Lower Display
Prompt
Upper Display
Range of Setting
or Selection
Parameter
Definition
DECMAL
XXXX [factory setting]
XXX.X
XX.XX
DECIMAL POINT LOCATION—This selection determines where
the decimal point appears in the display.
None
One Place
Two Places
NOTE: Be sure the selection agrees with the value to be displayed.
If PV requires 4 whole digits, the decimal will not show. Value of “IN
TYP” parameter must be for a linear input type for two decimal
places to be displayed.
UNITS
NONE
F [factory setting]
C
TEMPERATURE UNITS—This selection will be indicated on the
PV display.
No units
Degrees Fahrenheit
Degrees Celsius
