Honeywell DR4312 User Manual

Configuration, Startup, and Operation
of Recorder without Display
4/00 DR4300 Circular Chart Recorder Product Manual 59
o = off n = on
Any RTD marked with an asterisk is IEC Alpha = 0.00391
All other RTDs are IEC Alpha = 0.00385
x in column for SW6 switch 2 = see Subsection 3.2.2
Input
Type
Chart Type Con-
fig #
EU Non-
Lin
CONFIG Switches
(SW1)
INPUT Switches
(SW6)
Chart Part
Number
R56
***
12345678 123456
RTD
0 to 200 °C
7 Day
33 x
noooonoo oonono
in
RTD
0 to 200 Even
24 Hr
131 °F
n nooooon oonono
1660-010 in
RTD
0 to 200 Even
24 Hr
134 °C
onnoooon oonono
1660-010 in
RTD
0 to 200 Even
7 Day
137 °F
noonooon oonono
1661-004 in
RTD
0 to 200 Even
7 Day
140 °C
oon nooon oonon o
1661-004 in
RTD
0 to 200 Even
12 Hr
191 °C
nnnnnnon oonono
1903-003 in
RTD
–90 to 210 Even
24 Hr
141 °C
nonnooon oonono
in
RTD
–90 to 210 Even
7 Day
142 °F
onn nooon oonono
in
RTD
–90 to 210 Even
7 Day
280 °C
ooon n ooo oon on o
out
RTD
–90 to 210 Even
24 Hr
281 °F
noonnooo oonono
in
RTD
–50 to 250 Even
24 Hr
194 °C
onoooonn oonono
in
RTD
–50 to 250 Even
7 Day
195 °C
nnoooonn oonono
1661-642
(dual range chart)
in
RTD
0 to 250 °F
24 Hr
36 x
oon oon oo oo no n o
1660-068 in
RTD
0 to 250 Even
7 Day
251 °F
nnon nn n n oonono
in
RTD
50 to 250 Even
7 Day
208 °F
oooon o n n oon o no
1661-003 in
RTD
50 to 250 Even
24 Hr
209 °F
nooononn oonono
1660-008 in
RTD*
–75 to 260°C
24 Hr
266 x
ononoooo oonono
1660-055 out
RTD*
–75 to 260°C
7 Day
267 x
nnonoooo oonono
1661-055 out
RTD
0 to 300 Even
24 Hr
144 °C
oooon oon oon on o
1660-050 in
RTD
0 to 300 Even
24 Hr
145 °F
nooonoon oonono
1660-050 in
RTD
0 to 300 Even
7 Day
146 °C
onoonoon oonono
1661-050 in
RTD
0 to 300 Even
7 Day
147 °F
nnoonoon oonono
1661-050 in
RTD
0 to 350 Even
24 Hr
218 °F
ononnonn oonono
1660-037 in
6
5
4
3
2
1
INPUT SWITCHES
ON
8
7
6
5
4
3
2
1
CONFIG SWITCHES
ON
